LED batten lights are rapidly replacing dated fluorescent tube technology in retail, commercial and industrial applications, as well as residential installations like garages and utility rooms. Their principal advantages are significantly lower power consumption and longer life spans. Just as fluorescent tubes replaced incandescent light bulbs because they were far more energy-efficient, replacing fluorescent batten lights with LED batten fittings will yield substantial energy savings.
LED Batten Light Features:
1. Extruded aluminum profile with white spraying color;
2. Detachable housing simplifies installation and maintenance process;
3. Energy saving;
4. 50,000 hours long lifespan.
Dimension:
| Model Number | A(L=mm) | C(W=mm) | D(H=mm) |
| BA003-06C020 | 600 | 80 | 67 |
| BA003-12C040 | 1200 | 80 | 67 |
| BA003-15C060 | 1500 | 80 | 67 |
Technical Specifications:
| Model Number | Size | Power | Input Voltage | Luminous | Lumen | CCT | CRI | PF | IP Rate | |||||||||||
| BA003-06C020 | 600mm | 20W | AC220-240V | 120lm/W | 2400lm | 3000K-6500K | >80Ra | >0.95 | IP20 | |||||||||||
| BA003-12C040 | 1200mm | 40W | AC220-240V | 120lm/W | 4800lm | 3000K-6500K | >80Ra | >0.95 | IP20 | |||||||||||
| BA003-15C060 | 1500mm | 60W | AC220-240V | 120lm/W | 7200lm | 3000K-6500K | >80Ra | >0.95 | IP20 |
Packaging:
Each lamp packs with an individual cardboard box and master carton.
8PCS/CTN
1225x380x170mm
18.5KGS/CTN
1. Trade & Shipping Terms:
1) Payment: 30% T/T in advance, the balance before delivery.
2) Lead time: 3-5 days for sample order; 12-15 days for bulk order.
3) Shipment: DHL, FedEx, UPS, TNT, By Sea, By Train.
4) Nearest port: Shenzhen or Guangzhou or Hong Kong
2. Customization:
1) Custom color box: please send us your design, we will ask printing company help to do it.
2) Logo on product: please send us your logo, we can laser printing it on the product.
3) Custom product: if you need some special product, please tell me the detail, our engineer will help us to make it true.
3. Quality:
1) Certificate: our products with CE, RoHS and TUV certificate, production strictly complying with ISO9001:2015.
2) Material control: all material will be tested before bulk production.
